Profiling Router Bits: Beading Router Bits, Carbide Tipped: 5/16″ Rad x 1-1/8″ Dia x 1/2″ x 1/4″ Shank
Cut a quarter-round shape bounded by fillets, known as a bead, in one pass by this bit. The width of one fillet is set by the pilot bearing size, while the other is controlled by the depth of cut. A beading bit can be transformed into a corner rounding bit by changing the bearing (& vice versa).
Standard Equipment:
49608 Beading Router Bit
Specifications:
Radius (R): 5/16″
Diameter (D): 1-1/8″
Cutting Height (B): 1/2″
D1: 3/8″
Shank (d): 1/4″
Overall Length (L): 2-1/16″
Flutes: 2
Replacement Bearing: 47702
Features:
High quality long lasting European sub-micrograin & micrograin carbide
Thick carbide for multiple resharpenings
Different carbide grades for different materials
Silver induction brazing for maximum carbide bonding strength
Produced according to Holz-BG German standards for safety and quality
Centerless ground shank for exact fit
Multi axis grinding
Bodies manufactured in single clamping for superior balance, symmetry, precision and centricity
Use of only solid bar stock steel (brazed bits)
Shanks laser etched with size, maximum RPM ratings and clamping depth
